Auto Feeding Kiss Cut Die Cut Half Cut Cutting Machine

Auto Feeding Kiss Cut Die Cut Half Cut Cutting Machine

Overview Product Description SG-ASC420 Features: 1.Two groups of tools including roland blade and creasing tool;Tangenti
Basic Info
Model NO. SG-ASF420
Computerized Computerized
Automatic Grade Semi-Automatic
Application Paper Packaging Materials, Stickers Products
Cutting Media Types Self-Adhesive Sticker, Cardboard, Corrugated Paper
Media Hold Method Vacuum Suction
Operation Mode Front / Rear Scanning and Front / Rear Cutting / M
Maximum Feeding Size A2 420*594mm
Programmable Resolution Hpgl 0.025mm
Repeat Precision ≤0.05mm
Transport Package Wooden Case
Specification 186*148*62cm
Trademark SAGA
Origin Hefei China
HS Code 84411000
Production Capacity 1500/Year
Product Description

SG-ASC420

Features:
1.Two groups of tools including roland blade and creasing tool;Tangential blade and wheels type creasing tool.2.Self-development software/CorelDRAW plugin/Illustrator plugin3.Self-designed UI and touchscreen4.USB cable/USB/WiFi/Net share/Net cable/Inner disk/Software,different ways to output.
Application:
1.Cardboard up to 600gsm.All kind of sticker.2.PVC/PET/PP3.Corrugated paper no more than 0.3mm

1. Digital die-cutting crafts which meet mass production process standard 2. More intelligent interaction with 7-inch touch screen 3. 4 tools in 4 combinations 4. Automatic induction lifting feeder combined with independent paper feeding system 5. Feeding, REAR scanning and REAR cutting separately with non-interference 6. Wider application scenarios with wider format and thicker material 7. More medias can be placed up to 18 CM stacking 8. The speed are greatly improved both on scanning and running
Detailed PhotosProduct Parameters
Model nameSG-ASF420
Cutting control systemX-High-power brushless servo motor
Y-High-power brushless servo motor
Positioning sensor typeDigital camera(CCD)
Control panel7 inch capacitive touch screen
Number of tool holdersDouble tool holders
Blade typesBlade,creasing tool and pen
Number of tangential bladeDouble tool holders
Tangential blade typesBlade,creasing tool
Machine performance
Meida hold methodVacuum suction
Scanning code typeMark/QR code
Maximum width490mmx710mm
Maximum cutting size460mmx665mm
Scanning speed5-10s
Maximum Cutting ForceCreasing:0-1900gf(10gf 1step)
Blade:0-1900gf(10gf 1step)
Maximum Paper Weight600g(Varies from different cutting materials)
Mechanical resolution0.02mm
Programmable resolutionHPGL 0.025mm
Repeat precision≤0.05mm
Cutting Media TypesSelf-adhesive sticker,cardboard,corrugated paper,etc
Software and compatibility
ConnectivityUSB,TCP,WiFi,U disk,Innerdisk
Software and compatibilityCorelDraw/Illustrator Plugin(U disk interface)
Power and working environment requirements
Working voltage and current100VAC-120VAC,50/60Hz,Maximum current 13.6A
200VAC-240VAC,50/60Hz,Maximum current 6.8A
PowerMaximum 750W
Vacuum Pump voltage and current110VAC,50Hz,Rated current 10.8A,60Hz,Rated current 13.0A
220VAC,50Hz,Rated current 4.5A,60Hz,Rated current 5.6A
Power(Vacuum Pump)50Hz,750W;60Hz,840W
StandIncluded
Operation environmentTemperature +5ºC to +35ºC(Fahrenheit 41-95),Humidity 30%-75%(Non-condensing)
Dimensions and Weight
Actual dimensions930mm*860mm*940mm(Feeding platform) 1595mm*810mm*940mm(Flatbed cutter)
Package dimensions1095mm*1031mm*1417mm(Feeding platform) 2168mm*1298mm*1332mm(Flatbed cutter)
Gross/Net weight128±25kg/191kg±25kg(Feeding platform) 267±25kg/402±25(Flatbed cutter)
