Automatic Roll Label 320 Flatbed Die Cutting Machine Shaper

Basic Info

Model NO.	MQ-320S
Automatic Grade	Automatic
Application	Paper Packaging Materials, Stickers Products, Heat Insulation Material, Insulating Materials, Dust-proof Material, EMI Shielding Materials
Driven Type	Electric
Driven System	Servo Motor
Control	PLC
Machine Type	Die Cutting Machine
Experience	Over 30 Years
Die Cutter Type	Kiss Cut/Half Cut
Extra Function	Can Add Hot Foil Stamping/ Laminating/ Sheet Cutte
Condition	New
Transport Package	Wooden Case
Specification	2350*1250*1600mm
Trademark	CHUANRI
Origin	China
HS Code	8411100000
Production Capacity	100 Sets/Month

Product Description

Automatic Roll Label 320 Flatbed Die Cutting Machine Shaper

Function And Characteristic1. The frame of machine is iron casting, which makes sure mahcine is strong enough. We have our own advanced CNC center, which makers sure the production of the machine with high precision. Which make sure it stable , long lifetime and heavy die cut pressure.2. Closed oil is used for avoid rusty of the gear box. Most important thing is that it can reduce the friction. Meantime, we can get a quite working surrounding. 3. Three working mode : single die cut, continuous die cut, jogging . Easier to operate.4. Automatic lubrication system, it can offer oil together.5. It is helpful to improve the die cut speed. 260 cuts/min . Such speeds is 50% faster than traditional die cutting machine.6. Servo trasmission is used of instead of tradition clutch structure to control the sheet cutter. It is helpful to get more accurate cut under faster die cut speed. And continuous cutting function is helpful to get lifetime of the cutter. ApplicationThis machine is suitable for convert adhesive label, protective film, electronic shielding materials, pvc, film, malay, copper foil, aluminum foil, double adhesive, foam etc. And also can used in reflector plate, diffuser, buffer plate,silicon tape etc for LCD.Main parameters

Model	MQ-S-320
Max feeding width	320mm
Die cut speed	≤260cuts/min
Precision	±0.10mm
Cutting area	300*300mm
Main power	3kw
Voltage	380v
Weight	1350kg
Size	L*2350*W1250*H1600mm
Total power	6kw

Samples
Can die cutter adhesive labels, plastic films, rubber foam, double sided tape, aluminum foil tape etc.
Can roll rewind or sheet cutter.

Standard machine consist of unwind and host part.

Company information

SUZHOU CHUANRI PRECISION MACHINERY CO., LTD is a professional manufacturer of Flatbed Die cutting machines, Rotary die cutting machine, Slitting rewinding machines, Roll to sheet cutting machine, Laminating machines etc. Our Company Competitive Advantage:A. 33 years' experience in specializing production.B. Good quality and reliabilityC. Good reputation from domestic and oversea gained by good cost performanceD. Good and comprehensive after-sales serviceE. Excellent fulfillment in customization





Package and shipping
